适用范围：
小型模具、烫金梗、电机、高周波横、微量射出模、鞋模、微章、压花模具。饼干、巧克力、糖果模具。艺术品雕刻、刻度盘、字模、字型。各类标志、商标、拉链、钟表、餐具。可随时加旋转轴执行圆筒加工。
For metal mold processing, For Small molds, gold stamping stem, motors micro injection mold, shoe mold, emblems, embossing mold. Biscuits, chocolate, candy molds. Art sculpture, dial, character. Various types of marks, trademarks, zipper, watches, tableware. It also can do rotary cylinder process.
配置参数：
型号 |
NO.discription |
Parameter |
NPS-0304
NPS-0405
NPS-0506 |
加工尺寸 |
Working Area(X×Y×Z) |
360×400×100mm
400×500×100mm
500×600×100mm |
| 主轴分辨率 |
Spindle(KW) |
2.2KW恒功率主轴
2.2KW constant power spindle |
| 最大加工速度 |
Max Engraving Speed |
25000mm/min |
主轴转速
分辨率 |
Spindle Speed
Resolution |
6000-24000rpm
0.01mm |
| 重复定位精度 |
Repeatability |
0.005mm |
| 工作电压 |
Voltage |
AC240/220V/50HZ |
工作方式 |
Drive motor |
Stepper(Option,servo)
伺服（选配：步进） |
| 运行指令 |
Command language |
HPGL，G Code |
控制系统 |
Operating system |
NC studio
(option:Taiwan SYNTEC/LNC)
维宏（选配：台湾宝元、新代） |
机器特点：
◆床身整体铸造，坚定和不变形。高刚性，精度高，采用直线导轨。
◆采用高速驱动马达，速度比原机型提高近2倍。
◆防尘结构，保证长期运行性能。兼容性好，可以兼容Typle3, Artcam, castmate, Pro-E, CorelDraw CAD/CAM软件，可以加工浮雕，二维和三维产品。
◆Integrally cast lathe bed, firm and non-deforming,.high rigidity and high accuray, adopts straight line guide rail.
◆Use high speed drive motor, its speed enhanced nearly 2 meters higher than original type.
◆Uses the popular dustproof structure, which guarantee long-term performance characteristic. With good compatibility, this machine can work with many programs such as Typle3,Artcam. Castmate, proE, Coreldraw/CAD,CAM.The machine can engraving fine relief, 2Dan 3D products.
样品展示：
